Yellow standard-width brick-patterned metal carved exterior wall panels brick pattern Sandwich Panels are a new type of integrated thermal insulation material for building exterior walls. Metal carved exterior wall panels are a new type of integrated thermal insulation material for building exterior walls, offering thermal insulation, fire resistance, sound insulation, heat insulation, moisture resistance, easy cleaning, lightweight construction, and convenient installation. They typically come in sizes of 16mm (thickness) x 380mm/383mm (width) and can be custom-made in lengths of over 2 meters. The structural characteristics of these exterior wall panels make them popular for decorative insulation of new building exterior walls, such as villas, rural self-built houses, sentry booths, portable public toilets, transformer rooms, and garbage sorting rooms. They are also often used for renovation of existing building walls during rural revitalization.
Yellow Standard Width Brick Pattern Metal Carved Panel Exterior Wall Panel size specifications
| Product Name | Yellow Standard Width Brick Pattern Metal Carved Panel Exterior Wall Panel |
| Material | Surface: Galvalume-coated steel |
| Interlayer: Rigid polyurethane foam |
| Base: Aluminum foil anti-corrosion layer |
| Dimensions | Effective width: 383mm |
| Thickness | 16mm/20mm |
| Length | Customizable, ranging from 2-6 meters for easy transport |
| Net Weight | 3.5kg/m2 |
| Installation | Snap-in fastener assembly |
The core advantages of Yellow Standard Width Brick Pattern Metal Carved Panel Exterior Wall Panel are:
1. Highly decorative: Through an embossing process, a variety of textures, including fine brick, coarse brick, and standard brick, are achieved. A rich color palette allows them to mimic the visual effects of traditional ceramic tiles and stone. They can also be combined with wood and stone grains to enhance the layered appearance of building facades.
2. All-weather adaptability: Withstanding extreme cold and heat, UV aging, and acid, alkali, and salt corrosion, these panels are suitable for humid areas or complex environments. Their surface is easy to clean, reducing ongoing maintenance costs.
3. Fire and safety performance: Using a composite structure of metal steel and polyurethane, these panels achieve a fire rating of B2 (some products are B1). They are also lightweight, earthquake-resistant, and soundproof, enhancing building safety.
Product structure and core performance parameters of Yellow Standard Width Brick Pattern Metal Carved Panel Exterior Wall Panel
1. Materials and structure
Brick-patterned metal exterior wall panels usually adopt a composite structure of "metal panel + polyurethane insulation layer + backing layer":
(1) Panel: Mostly 0.2-0.5mm thick color steel plate or aluminum-zinc plate, the surface is processed by embossing machine to form a brick pattern, such as JKM-S600 embossing machine can customize brick pattern, plain pattern and other flower roller patterns.
(2) Insulation layer: The core is polyurethane foam material Metal Carved Panel Exterior Wall Panel, the insulation effect is twice that of the same thickness polystyrene board, effectively reducing heating and cooling energy consumption.
2. Key performance indicators
(1) Brick-pattern series metal exterior wall panel insulation effect: The polyurethane insulation layer has a low thermal conductivity, excellent cold-resistant and heat-insulating properties, and significant energy-saving efficiency
(2) Brick-pattern series metal exterior wall panel fire rating: The mainstream products reach B2 level, and some upgraded models reach B1 level, meeting the building fire protection regulations
(3) Brick-pattern series metal exterior wall panel service life: When using fluorocarbon paint coating, the panel weather resistance can reach more than 15 years
(4) Brick-pattern series metal exterior wall panel installation characteristics: Dry construction, lock-and-hang connection, local damage can be replaced separately, high installation efficiency and not restricted by seasons
Yellow Standard Width Brick Pattern Metal Carved Panel Exterior Wall Panel application scenarios and application cases
1. New buildings: brick-concrete structure, frame structure, steel structure, light steel villa, etc., such as light steel villa exterior wall, guardhouse, mobile board house.
2. Old renovation projects: Exterior wall decoration and energy-saving renovation of existing buildings, improving aesthetics while improving thermal insulation performance.
3. Special scenarios: steel structure guardhouses, container houses, mobile toilets, etc., temporary buildings that need to be waterproof and moisture-proof and quickly constructed
Factory display picture (all pictures are taken from real factory scenes)
Packaging and delivery display pictures (all pictures are taken from real factory scenes)
